TITAN COMBINED STRAPPING TOOL HPE-L

The HPE-L combines muscle power and pneumatics for both the Tensioning and Joining processes

SKU: ADL2012 Category:

Product information:
Every strapping procedure comprises a pair of distinct phases: tensioning and joining. The HPE-L model seamlessly integrates human strength with pneumatic functionality for executing both of these phases. The device employs pneumatic force to achieve strap tension of up to 7,000 N, whereas the joining process remains under manual control.

The HPE-L not only inherits the benefits of the HKE model but also enhances them through improved user-friendliness and the consistent application of high tensioning force facilitated by pneumatic propulsion. This innovative approach conserves valuable energy, particularly when dealing with flat packages.

Advantages

  • Saves valuable energy when working with flat packages
  • User-friendly with a high tensioning force

Specification:
COMBINED STRAPPING TOOL HPE-L

Technical Data:

Kind of drive (tensioning)Pneumatic
Tension forceUp to 7000N
Kind of drive (Sealing)Manually
Dimensions600x610x618mm (LxWxH)

23.6×24.0x24.3″(LxWxH)

Weight5.5KG
Air pressureMax. 6 bar flow pressure
Air consumption (During tensioning)12.7 ft³ / min.
Type of strapSteel Strap
Strap Width13mm, 16mm, 19mm
Kind of sealSealless-joint
Sealing strength
(depending on strap quality, strap dimensions)
up to approx. 75% of the strap breaking load

View the rest of our range and frequently asked questions about pneumatic steel strapping hand tools
